Type F Grill Ventilation

Date:2020-06-01 Click:396 Share to:

Model	DN(mm)	a*b(mm)	B*L(mm)	e	f	n
BMMOEMVMP001	100	60*1140	100*180	66	100	6
BMMOEMVMP001	100	80*120	120*160	86	90
BMMOEMVMP002	125	60*220	100*260	66	140
		80*160	120*200	86	110
		100*130	140*170	106	95
BMMOEMVMP003	150	80*250	120*290	86	155
		100*210	140*240	106	130
		120*150	160*190	126	105
BMMOEMVMP004	175	80*350	120*390	86	205	8
		100*250	140*290	106	155
		120*210	160*250	126	135
BMMOEMVMP005	200	100*350	140*390	106	205
		120*280	160*320	126	170
		150*220	190*260	156	140
BMMOEMVMP006	250	120*470	160*510	126	265	10
		150*350	190*390	156	205
		190*280	230*320	196	170
BMMOEMVMP007	300	150*530	150*570	156	295	12
		190*390	230*430	196	225
		240*300	280*340	246	180
BMMOEMVMP008	350	190*550	230*590	196	305
		240*420	280*460	246	240
		290*360	330*400	296	210
BMMOEMVMP009	400	190*760	230*800	196	410	14
		240*550	280*590	246	305
		290*460	330*500	296	260
