Type M Composite Rock Wool Wall Panel
Date:2020-06-03 Click:480 Share to:
Type M Composite Rock Wool Wall Panel
Type M Composite Rock Wool Wall Panel |
||
Product NO. |
BMMOEPWTM001 |
BMMOEPWTM002 |
Fireproof Class |
B-15 |
B-0 |
Dimension |
5Omm(T)*550mm(W)*Required Length(Max3500mm) |
3Omm(T)*550mm(W)*Required Length(Max3500mm |
Weight |
20.1kg/㎡ |
16.9kg/㎡ |
Thermal Transmittance |
0.58Kcal/㎡h.℃ |
1.13Kcal/㎡h.℃ |
Surface Finish |
PVC film or galvanized steel |
|
Core Material |
Rock Wool 150kg/㎡ |
|
Tolerances |
B 0`-1, H +3, T 0~-1 |
|
