4" Diesel Self-priming Fire Pump

4" Diesel Self-priming Fire Pump

Suction，discharge port diameter :   100mm（4inch）

Max capacity:  96 m3 /h

Engine: 30HP, 6.3kw

Pump head:   31m

Self-priming time : 180 s/4m
Maximum suction depth:   8m

Model of engine:  ST40DP

Engine type: Single-cylinder，vertical，4-stroke air-cooled diesel engine

Displacement: 418 cl

Starting systerm: manual

Rated speed : 3600rpm

Tank capacity: 5.5L

Bore X stroke: 80X70 mm

Appearance dimension: 650×480×610 mm
