BJ-22A Fire Fighting Pumps
Date:2020-06-09 Click:217 Share to:
BJ-22A Fire Fighting Pumps
35Hp fire pump with light weight, compact structure, high performance, widely used for fire fighting, irrigation
Appearance dimension |
750*610*650mm |
Device weight |
≤105kg |
Rated capacity |
1080L/min |
Pump head |
145m |
Out pressure |
0.7Mpa |
Inlet size |
φ80mm |
Out size |
φ65mm |
Dia.of nozzle |
φ19mm |
Type of inlet |
Screw type |
Maximum suction depth |
9m |
Pump priming time |
≤20s |
Starting way |
Recoil/Electric start |
Model of engine |
35HP, Briggs & Stratton |
Pump body |
twin stage |
