BJ-20A Fire Pump

Date:2020-06-09  Click:315   Share to:

  • BJ-20A Fire Pump

    BJ-20A Fire Pump

    BJ-20A is powered by HONDA GX690 Gasoline engine and the single-level centrifugal pumps . It has features of compact structure, start convenient, fast water, low fuel consumption, light weight and reliable, so that is more suitable for using in the narrow roads. It is the ideal equipment for fire extinguishing used in fire brigade, professional fire brigade, forest fire brigade, towns, rural areas, the mining industry and obligation fire brigade.





    Technical parameters:

    Appearance dimension   750×610×650mm;

    Pump Inlet         Φ80mm;

    Pump outlet     Φ65mm;

    Device weight  82kg;

    Maximum output power   27HP/3600r/min;

    Starting method  electric start/ manual start;

    Rated flow pump   1440L/min/0.8Mpa;

    Pump priming time   20s;

    Maximum suction depth    9m

    Pump lift      90m
