Electric Mooring Capstan
Electric Mooring Capstan
|
Product No.
|
Main Technical Specification
|
Warping Load(kN)
|
Warping Speed(m/min)
|
Wire Dia.(mm)
|
Motor Power(kW)
|
BMDM-ECB-01
|
5
|
≥18
|
Ф11
|
3/1.2
|
BMDM-ECB-02
|
10
|
≥18
|
Ф11
|
4.3/1.7
|
BMDM-ECB-03
|
15
|
≥18
|
Ф13
|
8.5/3.5
|
BMDM-ECB-04
|
20
|
≥18
|
Ф15
|
11/11/7.5
|
BMDM-ECB-05
|
30
|
≥18
|
Ф17.5
|
16/16/11
|
BMDM-ECB-06
|
50
|
≥18
|
Ф20.5
|
16
|
BMDM-ECB-07
|
70
|
≥18
|
Ф26
|
22
|
BMDM-ECB-08
|
100
|
≥18
|
Ф28
|
45/45/30
|
BMDM-ECB-09
|
120
|
≥18
|
Ф32.5
|
60/60/45
|
BMDM-ECB-10
|
150
|
≥18
|
Ф36.5
|
60/60/45
|
BMDM-ECB-11
|
200
|
≥18
|
Ф40
|
75/75/36
|
BMDM-ECB-12
|
250
|
≥18
|
Ф46
|
75/75/36
|
BOCHI Marine/Ship Equipment Department is a total solution provider with his head office in Chongqing Bochi Machinery Import and Export Co.,ltd.we are able to provide value added services and qualified marine equipments.
Deck equipments is one of our main products.including mooring winch, windlass, capastan, steering gear, marine crane, deck fiitings, shark jaw and towing pin, stern roller, hydraulic pump station, davit, etc.
For Marine Equipments, we could offer good quality with class certificate, including ABS, BV, CCS, DNV,GL, LR, KR,NK,RINA,RMRS ,etc.
