Electric Anchor Mooring Capstan
Electric Anchor Mooring Capstan Drawing
Main Technical Specification
|
Product No.
|
Chain Dia.(mm)
|
Working Load(kN)
|
Working Speed(m/mim)
|
Warping Load(kN)
|
Warping Speed(m/min)
|
Wire Dia.(mm)
|
Motor Power(kW)
|
BMMDEACEL-001
|
11/14
|
5.9/7.4
|
≥12
|
5
|
≥10
|
Ф11
|
3/1.2
|
BMMDEACEL-002
|
16/17.5
|
10.9/13.0
|
≥12
|
8
|
≥10
|
Ф13
|
4.3/1.7
|
BMMDEACEL-003
|
19/22
|
15.3/20.6
|
≥12
|
10
|
≥10
|
Ф13
|
6/2.5
|
BMMDEACEL-004
|
24/26
|
24.5/28.7
|
≥9
|
20
|
≥8.5
|
Ф15
|
7.5/7.5/5
|
BMMDEACEL-005
|
28/30
|
33.3/38.3
|
≥9
|
30
|
≥8.5
|
Ф17.5
|
16/16/11
|
BMMDEACEL-006
|
32/34/36
|
43.5/49.1/55.1
|
≥9
|
30
|
≥8.5
|
Ф17.5
|
16/16/11
|
BMMDEACEL-007
|
38/40/42
|
61.4/68.0/75.0
|
≥9
|
50
|
≥8.5
|
Ф20.5
|
22/22/16
|
BMMDEACEL-008
|
44/46/48
|
82.3/89.9/97.9
|
≥9
|
50
|
≥8
|
Ф26
|
30/30/22
|
BMMDEACEL-009
|
50/52/54
|
106.3/114.9/123.9
|
≥9
|
60
|
≥8
|
Ф26
|
30/30/22
|
BMMDEACEL-010
|
56/58/60
|
133.3/143.0/153.0
|
≥9
|
60
|
≥8
|
Ф26
|
45/45/30
|
BOCHI Marine/Ship Equipment Department is a total solution provider with his head office in Chongqing Bochi Machinery Import and Export Co.,ltd.we are able to provide value added services and qualified marine equipments.
Deck equipments is one of our main products.including mooring winch, windlass, capastan, steering gear, marine crane, deck fiitings, shark jaw and towing pin, stern roller, hydraulic pump station, davit, etc.
For Marine Equipments, we could offer good quality with class certificate, including ABS, BV, CCS, DNV,GL, LR, KR,NK,RINA,RMRS ,etc.
Any Inquiry or Questions, Pls Kindly Contact Us!
|
