Wire Rope Spur Gear Steel Hand Winch
Wire Rope Spur Gear Steel Hand Winch Drawing
|
Main Technical Specification
|
Product No.
|
Lifting / Pulling cap. 1st rope layer daN
|
Lifting / Pulling cap. Top rope layer daN
|
Crank effort 1st rope layer daN
|
Ratio
|
Recomm. rope diameter mm
|
Min. breaking load of Wire rope kN
|
Wire Rope storage max. mtr
|
Number of rope layers max.
|
Weight Without Wire rope kg
|
BMMDMWSGS-001
|
300
|
120
|
22
|
4.2:1
|
5
|
13.6
|
20
|
9
|
3.8
|
BMMDMWSGS-002
|
800
|
400
|
20
|
10:01
|
8
|
34.8
|
15
|
7
|
10.1
|
BMMDMWSGS-003
|
300
|
120
|
22
|
4.2:1
|
5
|
13.6
|
20
|
9
|
3.8
|
BMMDMWSGS-004
|
800
|
400
|
20
|
10:01
|
8
|
34.8
|
15
|
7
|
10.1
|
BOCHI Marine/Ship Equipment Department is a total solution provider with his head office in Chongqing Bochi Machinery Import and Export Co.,ltd.we are able to provide value added services and qualified marine equipments.
Deck equipments is one of our main products.including mooring winch, windlass, capastan, steering gear, marine crane, deck fiitings, shark jaw and towing pin, stern roller, hydraulic pump station, davit, etc.
For Marine Equipments, we could offer good quality with class certificate, including ABS, BV, CCS, DNV,GL, LR, KR,NK,RINA,RMRS ,etc.
Any Inquiry or Questions, Pls Kindly Contact Us!
|
