Double Bollards NS-2584

Date:2020-06-12 Click:385 Share to:

Double Bollards NS-2584

Double Bollards NS-2584 Double Bollards NS-2584 Drawing
Product No.	Type	F		Dimension(mm)						Weight(kg)
Product No.	Type	M	T	D	C	E	H	L1	L2	Weight(kg)
BMDM-DBNS-001	125	4.5	13.2	140	80	165	250	315	455	26
BMDM-DBNS-002	160	5.6	15.8	168	90	195	300	400	568	37
BMDM-DBNS-003	200	10.2	29	219	100	250	400	500	719	75
BMDM-DBNS-004	250	13.2	37.2	273	125	315	500	630	903	124
BMDM-DBNS-005	315	20.9	55	324	150	375	600	800	1124	230
BMDM-DBNS-006	400	28.5	75.4	406	175	435	700	1000	1406	356
BMDM-DBNS-007	500	52	123.6	508	200	515	830	1250	1758	723
BMDM-DBNS-008	630	62.7	158.1	610	225	615	1000	1570	2180	1084
BMDM-DBNS-009	710	83.1	219.3	711	250	675	1100	1750	2461	1532
