YGCH Supper Cell Rubber Fender

YGCH Supper Cell Rubber Fender Drawing

Product No.	Type(mm)	H	h	D1	D2	n-d	MD	h1	L
BMMMERFYG-001	YGCH400	400	25	550	650	4-30	22	10	270
BMMMERFYG-002	YGCH500	500	25	550	650	4-32	24	12	300
BMMMERFYG-003	YGCH630	630	30	700	840	4-39	30	14	330
BMMMERFYG-004	YGCH800	800	30	900	1050	6-40	32	14	360
BMMMERFYG-005	YGCH1000	1000	35	1100	1300	6-47	39	18	430
BMMMERFYG-006	YGCH1150	1150	40	1300	1500	6-50	42	22	500
BMMMERFYG-007	YGCH1250	1250	45	1450	1650	6-53	45	22	500
BMMMERFYG-008	YGCH1450	1450	47	1650	1850	6-61	52	26	570
BMMMERFYG-009	YGCH1600	1600	50	1800	2000	8-61	52	28	570
BMMMERFYG-010	YGCH1700	1700	55	1900	2100	8-66	56	30	620
BMMMERFYG-011	YGCH2000	2000	55	2000	2200	8-74	64	32	700
BMMMERFYG-012	YGCH2250	2250	60	2300	2550	10-74	64	36	700
BMMMERFYG-013	YGCH2500	2500	70	2700	2950	10-74	64	38	700
BMMMERFYG-014	YGCH3000	3000	75	3150	3350	12-90	76	40	800
Feature: 1.HighE/R.H (energy absorption/reaction.product height)
2.More Reasonable Structure
3.YGCH super cell rubber fender has the same installation bolt pitch and bolt with the general rubber fender
4.Minor affection in angular berthing
Accessories: Pre-built in U ring, Pre-built-in Bolt& Nut, Chains(Including tensile chain,weight chain&shear chain), Front Panel, Face Pad, Connector, Buffer.
