Model
|
BMMNCMI-015
|
General specification
|
Frequency Range
|
VHF140-160/150-170MHz
UHF:350-370/400-420MHz
UHF410-430/430-450MHz
UHF:430-450/450-470
|
Channel Capacity
|
100
|
Channel Spacing
|
25KHz
|
Operating temperature
|
-20 ℃to +60 ℃
|
Antenna impedance
|
50Ω
|
Working voltage
|
6.0V DC(±20%）
|
Battery capacity
|
700mAh(Li-ion)
|
Frequency stability
|
±5ppm
|
Dimension
|
58(L)×31(W)×102(H)mm
|
Weight
|
193g(including battery pack)
|
Transmitter
|
Power output
|
≤3W
|
Modulation mode
|
16K ￠F3E(width) 8K￠F3E(narrow)
|
Clutter& harmonic
|
≤ -36dBm
|
FM noise
|
≤ -40dB
|
Audio distortion
|
≤5%
|
Adjacent channel power
|
≥65dB
|
Modulation limit
|
≤5KHz
|
Receiver
|
Sensitivity (at 12dB SINARD)
|
≤0.165uV
|
Adjacent channel selectivity
|
≥60dB
|
Intermediation rejection ratio
|
≥60dB
|
Anti interfere of spurious wave
|
≥60dB
|
SNR
|
≥45dB
|
Audio output power
|
0.5W
|
Audio distortion
|
≤5%
|
Standard list
|
Hang rope,antenna,lithium battery,charger,belt,instruction
|
