Model
|
BMMEENPAP-006
|
Type
|
Dual rudder steering apparatus
|
Power
|
AC380V、50Hz；220V、50Hz；DC24V
A:three –phase 380V, ±5%
B:220V、50Hz，±5%
C:DC24V、3A,+10% ～ -10%
|
Steering
|
With the move, the manual
|
steering precision
|
≤1º
|
Ineffective area
|
0.5 º ~ 2 º adjustable;
|
Steering mode
|
±40º
|
Other
|
DHART mode can double pump
|
Supporting programs
|
No.
|
Name
|
Type
|
Quantity
|
Protection class
|
1
|
main instrument
|
DD101-ZT
|
1
|
IP22
|
2
|
1 # pump start box
|
SC9-K
|
2
|
3
|
2 # pump start box
|
SC10-K
|
2
|
4
|
Steering gear alarm box
|
CKD-4
|
2
|
5
|
Feedback rudder angle transmitter
|
DD101-WK
|
2
|
IP56
|
Alarm range :Dynamic power failure, overload, phase failure, power failure control, low oil level, oil temperature,
oil filter clogging, pressure difference, two servos are dual;
and an alarm test function and silencers after automatic reset function
|
