60 to 200T Hydraulic Anchor Handling Towing Winch

Hydraulic Anchor Handling Towing Winch

Anchor Handling Towing Winch(AHTW), Drums for towing,gypsies beside for Anchoring.Much experience in designing and producing big winch.

Specification:

1. Driven Mode: Hydraulic, Single/double/triple drums in waterfall arrangement
2. Configuration: Drums for anchor towing operation; Gypsies beside for Anchor operation
3. Spooling Device: on towing drum only
4. Rated Pull: 60 to 200Tonnes (1st layer)
5. Brake holding: first layer static up to 450Tones
6. Wire speed: multiple speed ranges available
7. Clutch: Hydraulic Operated
8. Brake: Spring loaded, hydraulically released for brake holding of 300Tonnes and below; Hydraulically operated for brake holding more than 300Tonnes
9. Dynamic Braking: To facilitate high load/high speed lowering without declutching
10. Hydraulic Motors: STAFFA or KYB motors.
11. Release: Emergency quick release
12. Control: Local Control for maintenance; Remote Control for operation
13. Options: Length and tension monitoring systems; Gypsies on lower drum shaft; Spooling device for anchor handling drum

BOCHI Marine/Ship Equipment Department is a total solution provider with his head office in Chongqing Bochi Machinery Import and Export Co.,ltd.we are able to provide value added services and qualified marine equipments.

Deck equipments is one of our main products.including mooring winch, windlass, capastan, steering gear, marine crane, deck fiitings, shark jaw and towing pin, stern roller, hydraulic pump station, davit, etc.

For Marine Equipments, we could offer good quality with class certificate, including ABS, BV, CCS, DNV,GL, LR, KR,NK,RINA,RMRS ,etc.

Any Inquiry or Questions, Pls Kindly Contact Us!
